Adet bazlı fiyat
- 1+ adet$0.54
- 10+ adet$0.51
- 100+ adet$0.48
- 500+ adet$0.45
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pitch
- 0.146 3.70mm
- Style
- Terminator (Shorting)
- Kurşunsuz Kodu
- yes
- Total Number Of Contacts
- 2
- Body Length Or Diameter
- 0.439 inch
- Contact Gender
- FEMALE
- RoHS Durumu
- ROHS3 Compliant
- Plating Thickness
- 40μin
- Contact Materials
- Phosphor Bronze
- Reliability
- COMMERCIAL
- Insulation Resistance
- 1000000000Ohm
- Parça Durumu
- Obsolete
- Housing Color
- White
- Nominal Gerilim
- 500V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL
- Mating Cycles
- 15
- Ambalaj
- Bulk
- Pozisyon Sayısı
- 2
- Body Depth
- 0.358 inch
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 1
- Termination Type
- CRIMP
- Fastening Type
- Latch Lock
- Current Rating Amps
- 2A
- Connector Type
- Receptacle
- Fabrika Tedarik Süresi
- 13 Weeks
- Additional Feature
- ROHS AND ELV COMPLIANT
- Mounting Option1
- LOCKING
- Polarization Key
- POLARIZED HOUSING
- Seri
- Flexi-Mate 503474
- Contact Resistance
- 40mOhm
- Yayın Yılı
- 2009
- Contact Finish
- Tin
- Montaj Tipi
- Free Hanging (In-Line)
- Çalışma Sıcaklığı
- -40°C~80°C
- Contact Design
- PREASSEM CONN
- Housing Material
- Polybutylene Terephthalate (PBT), Polyester
