009159002502906

Teknik Özellikler

Esr Equivalent Series Resistance

5.1 mOhms

Applications

High Frequency, Switching; High Pulse, DV/DT; Snubber

Current Rating Amps

2A per Contact

Voltage Rating Dc

1500V (1.5kV)

Connector Type

Receptacle

Maks. Oturma Yüksekliği

1.299 (33.00mm)

Minimum Operating Temperature

- 40 C

Fabrika Paket Adedi

1000

Sıra Sayısı

1

Basehousing Material

Nylon

Birim Ağırlık

0.036005 oz

Nem Hassasiyeti (MSL)

3 (168 Hours)

Parça Durumu

Discontinued

Kılıf / Paket

Radial

Pitch

0.079 2.00mm

ECCN Kodu

EAR99

Body Orientation

Straight

Housing Color

White

Seri

9159

REACH Uyumluluk Kodu

unknown

Voltage Rating Ac

650V

Ambalaj

Cut Tape (CT)

Boyut / Ölçü

1.260 L x 0.709 W (32.00mm x 18.00mm)

Paket

Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;

Max Voltage Rating Ac

300V

Dielectric Material

Polypropylene (PP), Metallized

Termination Method

Solder

Style

Board to Board - Card Edge

Orientation

Straight

Montaj

Surface Mount

Voltage Rating

300 VAC

Çalışma Sıcaklığı

-40°C~120°C

RoHS Durumu

ROHS3 Compliant

Contact Materials

Copper Alloy

Kurşunsuz

Lead Free

Ürün Tipi

Board to Board & Mezzanine Connectors

Mounting

Surface Mount

Mounting Angle

Straight

Akım Değeri

2A

Mating Cycles

10
