009159002001106

Teknik Özellikler

Ambalaj

Tape & Reel (TR)

Iec Conformance

NO

Paket

Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;

Din Conformance

NO

Termination Method

Solder

Max Voltage Rating Ac

250V

Style

Board to Board - Card Edge

Pitch

0.079 2.00mm

ECCN Kodu

EAR99

Mil Conformance

NO

Body Orientation

Right Angle

Housing Color

White

Seri

9159

Filter Feature

NO

Minimum Operating Temperature

- 55 C

Fabrika Tedarik Süresi

8 Weeks

Mixed Contacts

NO

Fabrika Paket Adedi

750

Option

GENERAL PURPOSE

Sıra Sayısı

1

Direnç

5.1 kΩ

Flammability Rating

UL94 HB

Basehousing Material

Nylon 46

Nem Hassasiyeti (MSL)

1 (Unlimited)

Parça Durumu

Active

Radyasyon Dayanımı

No

Reach Svhc

No SVHC

Current Rating Amps

3A per Contact

Gender

Receptacle

Connector Type

Adapter, Bridge

Terminal

Solder

Housing Material

Polyamide (PA46), Nylon 4/6

Tolerans

2 %

Contact Finish

Tin

Montaj Tipi

Free Hanging (In-Line)

RoHS

Non-Compliant

Nominal Gerilim

300V

Ürün Durumu

Active

Maks. Çalışma Sıcaklığı

+ 125 C

Mating Cycles

5
