Adet bazlı fiyat
- 1+ adet$0.12
- 10+ adet$0.11
- 100+ adet$0.11
- 500+ adet$0.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Additional Feature
- ROHS AND ELV COMPLIANT
- Contact Finish Mating
- NOT SPECIFIED
- Polarization Key
- POLARIZED HOUSING
- Mounting Option1
- LOCKING
- Montaj Tipi
- Free Hanging (In-Line)
- Yayın Yılı
- 2009
- Contact Resistance
- 40mOhm
- Seri
- Flexi-Mate 503473
- Housing Material
- Polybutylene Terephthalate (PBT), Polyester
- Çalışma Sıcaklığı
- -40°C~80°C
- Contact Design
- PREASSEM CONN
- Mating Cycles
- 15
- Contact Pattern
- RECTANGULAR
- Body Depth
- 0.331 inch
- Pozisyon Sayısı
- 2
- Ambalaj
- Bulk
- Fastening Type
- Latch Lock
- Terminal
- Crimp
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 19 Weeks
- Connector Type
- Plug Housing for Plug Contact
- Current Rating Amps
- 2A
- HTS Kodu
- 8536.69.40.40
- Reliability
- COMMERCIAL
- Contact Materials
- NOT SPECIFIED
- Nominal Gerilim
- 500V
- Housing Color
- White
- Insulation Resistance
- 1000000000Ohm
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL
- Pitch
- 0.146 3.70mm
- Style
- Board to Cable/Wire
- Total Number Of Contacts
- 2
- Body Length Or Diameter
- 0.48 inch
- Contact Gender
- FEMALE
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
