Adet bazlı fiyat
- 1+ adet$1.00
- 10+ adet$0.94
- 100+ adet$0.89
- 500+ adet$0.84
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Sıra Sayısı
- 1
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish
- Tin
- Connector Type
- Receptacle, Poke-In Wire
- Pozisyon Sayısı
- 2
- Fabrika Tedarik Süresi
- 11 Weeks
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Copper Alloy
- Style
- Board to Cable/Wire
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Number Of Ways
- 2
- Çalışma Sıcaklığı
- -60°C~130°C
- Seri
- Lite-Trap
- Current Rating Amps
- 5A 6A 9A
- Montaj Tipi
- Board Cutout, Surface Mount, Right Angle, Bottom Entry
- Nominal Gerilim
- 320V
- Pitch
- 0.157 4.00mm
- Housing Color
- Natural
- Yayın Yılı
- 2016
- Wire Gauge
- 18-24 AWG
- Safety Approval
- UL
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Additional Feature
- STANDARD: UL 94V-0, GLASS FILLED LCP
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Number Of Decks
- 1
