Specifications
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Fall Time Typ
- 5.2 ns
- Drive Voltage Max Rds On Min Rds On
- 2.5V 8V
- Yükseklik
- 1.1mm
- Power Dissipation Max
- 3W Ta
- Kurşunsuz
- Contains Lead
- Montaj Tipi
- Surface Mount
- Temel Parça No
- CSD16340
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Transistor Application
- SWITCHING
- Genişlik
- 3.3mm
- Kurşunsuz Kodu
- yes
- Power Dissipation
- 3W
- JESD-609 Kodu
- e3
- Pin Sayısı
- 8
- Vgsth Max Id
- 1.1V @ 250μA
- Drain To Source Voltage Vdss
- 25V
- Threshold Voltage
- 850mV
- Element Configuration
- Single
- Terminal Sayısı
- 5
- Feedback Capmax Crss
- 69 pF
- ECCN Kodu
- EAR99
- Additional Feature
- AVALANCHE RATED
- Fet Type
- N-Channel
- Input Capacitance Ciss Max Vds
- 1350pF @ 12.5V
- Rds On Max Id Vgs
- 4.5m Ω @ 20A, 8V
- Current Continuous Drain Id25
- 21A Ta 60A Tc
- Seri
- NexFET™
- Thickness
- 1mm
- Tepe Reflow Sıcaklığı (°C)
- 260
- Vgs Max
- +10V, -8V
- Gate To Source Voltage Vgs
- 10V
- Montaj
- Surface Mount
- Contact Plating
- Tin
- Reach Svhc
- No SVHC
- Parça Durumu
- Active
- Terminal Pozisyonu
- DUAL
- Number Of Elements
- 1
- Nominal Vgs
- 850 mV
- Operating Mode
- ENHANCEMENT MODE
