CSD16322Q5

Specifications

Fet Type

N-Channel

Dual Supply Voltage

25V

Feedback Capmax Crss

70 pF

ECCN Kodu

EAR99

Additional Feature

AVALANCHE RATED

Vgsth Max Id

1.4V @ 250μA

Pin Sayısı

8

Element Configuration

Single

Threshold Voltage

1.1V

Terminal Sayısı

5

Transistor Application

SWITCHING

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kurşunsuz Kodu

yes

Genişlik

6mm

Power Dissipation

3.1W

JESD-609 Kodu

e3

Montaj Tipi

Surface Mount

Kurşunsuz

Contains Lead

Power Dissipation Max

3.1W Ta

Temel Parça No

CSD16322

Terminal

SMD/SMT

Yükseklik

1.05mm

Çalışma Sıcaklığı

-55°C~150°C TJ

Fall Time Typ

3.7 ns

Drive Voltage Max Rds On Min Rds On

3V 8V

Fabrika Tedarik Süresi

6 Weeks

Transistor Element Material

SILICON

Gate Charge Qg Max Vgs

9.7nC @ 4.5V

Rise Time

10.7ns

Kılıf / Paket

8-PowerTDFN

Turn Off Delay Time

12.3 ns

Drainsource On Resistancemax

0.007Ohm

Radyasyon Dayanımı

No

Turn On Delay Time

6.1 ns

Uzunluk

5mm

Lifecycle Status

ACTIVE (Last Updated: 1 day ago)

Continuous Drain Current Id

97A

Ambalaj

Tape & Reel (TR)

Case Connection

DRAIN

Pin Sayısı

8
