Specifications
- Current Continuous Drain Id25
- 150mA Ta
- Fet Type
- N-Channel
- Drain Currentmax Abs Id
- 0.15A
- ECCN Kodu
- EAR99
- Ds Breakdown Voltagemin
- 20V
- Case Connection
- DRAIN
- Montaj
- Surface Mount
- Configuration
- SINGLE WITH BUILT-IN DIODE
- Operating Mode
- ENHANCEMENT MODE
- Drive Voltage Max Rds On Min Rds On
- 1.5V 4.5V
- Transistor Element Material
- SILICON
- Kılıf / Paket
- 3-XFDFN
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Surface Mount
- Vgs Max
- ±10V
- Terminal Formu
- NO LEAD
- Input Capacitance Ciss Max Vds
- 12pF @ 10V
- Drain To Source Voltage Vdss
- 20V
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Number Of Elements
- 1
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 16 Weeks
- REACH Uyumluluk Kodu
- not_compliant
- Rds On Max Id Vgs
- 2 Ω @ 150mA, 4.5V
- Transistor Application
- SWITCHING
- Ambalaj
- Tape & Reel (TR)
- Vgsth Max Id
- 1V @ 100μA
- Continuous Drain Current Id
- 150mA
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Power Dissipation Max
- 100mW Ta
- Yayın Yılı
- 2013
- Pin Sayısı
- 3
- Terminal Sayısı
- 3
- Terminal Pozisyonu
- BOTTOM
