Specifications
- Power Dissipation Max
- 3W Ta 50W Tc
- Element Configuration
- Single
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Rds On Max Id Vgs
- 10.5 Ω @ 1.25A, 10V
- Çalışma Sıcaklığı
- 150°C TJ
- Genişlik
- 15.5mm
- Vgs Max
- ±30V
- Turn On Delay Time
- 15 ns
- Terminal Kaplaması
- Tin (Sn)
- Weight
- 6.961991g
- Input Capacitance Ciss Max Vds
- 650pF @ 30V
- Current Continuous Drain Id25
- 2.5A Ta
- Transistor Element Material
- SILICON
- Pin Sayısı
- 3
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 43.8mm
- Reach Svhc
- No SVHC
- Turn Off Delay Time
- 140 ns
- Yükseklik
- 5.5mm
- Number Of Elements
- 1
- Montaj
- Through Hole
- Pulsed Drain Currentmax Idm
- 5A
- Drive Voltage Max Rds On Min Rds On
- 10V
- Terminal Sayısı
- 3
- Number Of Channels
- 1
- Pin Sayısı
- 3
- Fabrika Tedarik Süresi
- 24 Weeks
- Gate Charge Qg Max Vgs
- 34nC @ 10V
- Power Dissipation
- 3W
- Rise Time
- 24ns
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Kılıf / Paket
- TO-3PL
- Drain To Source Voltage Vdss
- 1500V
- Gate To Source Voltage Vgs
- 30V
- Continuous Drain Current Id
- 2.5A
