9994970000

Teknik Özellikler

Montaj Tipi

Through Hole

Number Of Positions Per Level

4

Seri

Omnimate LM

Wire Gauge

14-24 AWG

Ambalaj

Bulk

Pitch

0.200 5.08mm

Mating Orientation

Vertical with Board

Contact Material Plating

Copper Alloy - Tin Plated

Number Of Decks

1

Onay Kuruluşu

CSA, cURus

Terminal

Screw

ECCN Kodu

EAR99

Number Of Levels

1

Number Of Ways

4

Wire Gauge Min

14 AWG

Wire Gauge Max

24 AWG

Stripping Length

6mm

Renk

Orange

Akım Değeri

10A

Parça Durumu

Active

Terminal And Terminal Block Type

STRIP TERMINAL BLOCK

RoHS Durumu

RoHS Compliant

Çalışma Sıcaklığı

-50°C~120°C

Fabrika Tedarik Süresi

12 Weeks

Screw Thread

M2.5

Nem Hassasiyeti (MSL)

1 (Unlimited)

Akım

15A

Özellikler

Interlocking (Side)

Contact Plating

Tin

Housing Material

Thermoplastic, Wemid

Nominal Gerilim

300V

Wire Cross Section

2.5 mm2

Hole Diameter

1.3 mm

Flammability Rating

UL94 V-0

Wire Termination

Screw - Clamping Yoke, Tension Sleeve

Montaj

Through Hole

Sıra Sayısı

1
