Adet bazlı fiyat
- 1+ adet$2.60
- 10+ adet$2.46
- 100+ adet$2.32
- 500+ adet$2.19
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Contacts
- 6
- Montaj Tipi
- Through Hole
- Seri
- Omnimate LM
- Wire Gauge
- 14-24 AWG
- Ambalaj
- Bulk
- Contact Material Plating
- Copper Alloy - Tin Plated
- Mating Orientation
- 45° (135°) Angle with Board
- Pitch
- 0.200 5.08mm
- Number Of Decks
- 1
- Terminal
- Screw
- Number Of Ways
- 6
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 14 AWG
- Wire Gauge Max
- 24 AWG
- Safety Approval
- UL; CSA
- Gerilim
- 300V
- Renk
- Black
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Çalışma Sıcaklığı
- -50°C~120°C
- Screw Thread
- M2.5
- Fabrika Tedarik Süresi
- 16 Weeks
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım
- 15A
- Contact Plating
- Tin
- Özellikler
- Interlocking (Side)
- Housing Material
- Thermoplastic, Wemid
- Wire Cross Section
- 2.5 mm2
- Additional Feature
- STANDARD: UL 94V-0
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 1
- Montaj
- Through Hole
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Yayın Yılı
- 2008
