Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Seri
- PowerTrench®
- Pin Sayısı
- 3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Through Hole
- Kurşunsuz Kodu
- yes
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Turn Off Delay Time
- 80 ns
- Radyasyon Dayanımı
- No
- Jedec95 Code
- TO-220AB
- Power Dissipation Max
- 263W Tc
- Gate Charge Qg Max Vgs
- 203nC @ 10V
- Number Of Elements
- 1
- Element Configuration
- Single
- Uzunluk
- 10.1mm
- Operating Mode
- ENHANCEMENT MODE
- Vgs Max
- ±20V
- Terminal Sayısı
- 3
- Input Capacitance Ciss Max Vds
- 13280pF @ 25V
- Yükseklik
- 15.38mm
- Genişlik
- 4.7mm
- Vgsth Max Id
- 4.5V @ 250μA
- JESD-609 Kodu
- e3
- Power Dissipation
- 263W
- Continuous Drain Current Id
- 120A
- Additional Feature
- ULTRA-LOW RESISTANCE
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2004
- Ambalaj
- Tube
- Drainsource On Resistancemax
- 0.0055Ohm
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Threshold Voltage
- 3.5V
- Rds On Max Id Vgs
- 5.5m Ω @ 75A, 10V
- ECCN Kodu
- EAR99
- Parça Durumu
- Active
- Turn On Delay Time
- 44 ns
- Rise Time
- 92ns
- Fabrika Tedarik Süresi
- 9 Weeks
- Current Continuous Drain Id25
- 120A Tc
- Weight
- 2.421g
