Adet bazlı fiyat
- 1+ adet$0.07
- 500+ adet$0.05
- 1000+ adet$0.04
- 2000+ adet$0.04
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Kurşunsuz
- Lead Free
- Power Dissipation Max
- 400mW Ta
- Rds On Max Id Vgs
- 600m Ω @ 200mA, 4.5V
- Drive Voltage Max Rds On Min Rds On
- 1.5V 4.5V
- Parça Durumu
- Obsolete
- Montaj Tipi
- Surface Mount
- Vgs Max
- ±12V
- Turn Off Delay Time
- 13.74 ns
- Kılıf / Paket
- 3-UDFN
- Ambalaj
- Cut Tape (CT)
- Reach Svhc
- No SVHC
- JESD-609 Kodu
- e4
- Gate Charge Qg Max Vgs
- 500nC @ 4.5V
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Pin Sayısı
- 3
- Gate To Source Voltage Vgs
- 12V
- Fabrika Tedarik Süresi
- 40 Weeks
- Fet Type
- N-Channel
- Tepe Reflow Sıcaklığı (°C)
- 260
- Rise Time
- 7.28ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Ciss Max Vds
- 37pF @ 16V
- Number Of Channels
- 1
- Fall Time Typ
- 10.54 ns
- Continuous Drain Current Id
- 900mA
- Tepe Reflow Süresi (maks. sn)
- 40
- ECCN Kodu
- EAR99
- Drain To Source Breakdown Voltage
- 20V
- Current Continuous Drain Id25
- 900mA Ta
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Surface Mount
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Yayın Yılı
- 2012
- Vgsth Max Id
- 1V @ 250μA
- Turn On Delay Time
- 4.06 ns
