Specifications
- Input Voltage Viofficvce
- 500mV@100uA,5V
- Output Voltage Voonioii
- 300mV@10mA,0.5mA
- R1
- 4.7K+
- Input Resistor
- 4.7kΩ
- Vccv
- 50
- Resistor Ratio
- 10
- Collector Current Ic
- 100mA
- Paket
- Tape & Reel (TR)
- Dc Current Gain Hfeicvce
- 80@10mA,5V
- Power Dissipation Pd
- 150mW
- Collectoremitter Breakdown Voltage Vceo
- 50V
- Gi
- 80
- Pcmw
- 150
- Ioma
- 100
- RoHS
- true
- R2
- 47K+
- Transistor Type
- 1 NPN - bias preset
- Input Voltage Vionicvce
- 1.3V@5mA,0.3V
- Polarity
- NPN
- Voonv
- 0.3
