Specifications
- Maks. Oturma Yüksekliği
- 3.35mm
- Kılıf / Paket
- 900-BBGA, FCBGA
- Nem Hassasiyeti (MSL)
- 4 (72 Hours)
- JESD-609 Kodu
- e1
- Çalışma Sıcaklığı
- -40°C~100°C TJ
- Tepe Reflow Sıcaklığı (°C)
- 245
- Number Of Registers
- 554800
- Terminal Adımı
- 1mm
- Yayın Yılı
- 2010
- Core Processor
- Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
- Peripherals
- DMA
- Architecture
- MCU, FPGA
- Turn On Delay Time
- 120 ps
- Terminal Pozisyonu
- BOTTOM
- Interface
- CAN, EBI/EMI, Ethernet, I2C, MMC, SD, SDIO, SPI, UART, USART, USB
- Seri
- Zynq®-7000
- Terminal Sayısı
- 900
- Uzunluk
- 31mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Genişlik
- 31mm
- Max Supply Voltage
- 1.05V
- Parça Durumu
- Active
- Bus Compatibility
- CAN; ETHERNET; I2C; SPI; UART; USB
- HTS Kodu
- 8542.39.00.01
- ECCN Kodu
- 3A991.D
- Boundary Scan
- YES
- Connectivity
- CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
- Primary Attributes
- Kintex™-7 FPGA, 444K Logic Cells
- Propagation Delay
- 120 ps
- Min Supply Voltage
- 950mV
- Ram Size
- 256KB
- Tepe Reflow Süresi (maks. sn)
- 30
- Contact Plating
- Copper, Silver, Tin
- Montaj
- Surface Mount
- Frekans
- 800MHz
- Besleme Gerilimi
- 1V
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Additional Feature
- PL BLOCK OPERATES IN 0.97V TO 1.03V SUPPLY
- Core Architecture
- ARM
- Number Of Ios
- 130
