Specifications
- Akım Değeri
- 280mA
- Kurşunsuz
- Lead Free
- Uzunluk
- 3.5052mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Test Frequency
- 100kHz
- Çalışma Sıcaklığı
- -40°C~125°C
- Parça Durumu
- Obsolete
- Montaj
- Surface Mount
- Frequencyselfresonant
- 60MHz
- Dc Resistance Dcr
- 760mOhm Max
- Endüktans
- 10μH
- Boyut / Ölçü
- 0.138Lx0.130W 3.50mmx3.30mm
- Composition
- Wirewound
- Depth
- 3.5mm
- Tolerans
- ±30%
- Maks. Oturma Yüksekliği
- 0.041 1.05mm
- Min. Çalışma Sıcaklığı
- -40°C
- Materialcore
- Ferrite
- Kılıf / Paket
- Nonstandard
- Ambalaj
- Cut Tape (CT)
- Max Dc Current
- 280mA
- Reach Svhc
- No SVHC
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 2
- Inductance Tolerance
- 30%
- Montaj Tipi
- Surface Mount
- Maks. Çalışma Sıcaklığı
- 125°C
- Direnç
- 580mOhm
- Shielding
- Shielded
- Current Rating Amps
- 280mA
- Seri
- WE-TPC
- Rms Current Irms
- 280mA
- Genişlik
- 3.302mm
- Yükseklik
- 950μm
- Current Saturation
- 350mA
- Tip
- Wirewound
