Specifications
- Çalışma Sıcaklığı
- -25°C~85°C
- Nominal Gerilim
- 50V
- Actuator Material
- Liquid Crystal Polymer (LCP)
- Genişlik
- 2.1mm
- Montaj Tipi
- Surface Mount, Right Angle
- Uzunluk
- 31.4mm
- Locking Feature
- Slide Lock
- Gender
- Receptacle
- Özellikler
- Zero Insertion Force (ZIF)
- Akım Değeri
- 500mA
- Number Of Contacts
- 50
- Sıra Sayısı
- 1
- Kurşunsuz
- Lead Free
- Operating Supply Voltage
- 50V
- Parça Durumu
- Active
- Housing Color
- Ivory
- Pozisyon Sayısı
- 50
- Cable End Type
- Tapered
- Housing Material
- Liquid Crystal Polymer (LCP)
- Contact Finish Thickness
- 100.0μin 2.54μm
- Mating Cycles
- 25
- Height Above Board
- 0.079 2.00mm
- Contact Finish
- Tin
- Ambalaj
- Cut Tape (CT)
- Ffc Fcb Thickness
- 0.30mm
- Contact Location
- Top
- Flammability Rating
- UL94 V-0
- Lead Pitch
- 500μm
- Orientation
- Horizontal
- Maks. Çalışma Sıcaklığı
- 85°C
- Current Rating Amps
- 0.5A
- Terminal
- Solder
- Pin Sayısı
- 50
- Fabrika Tedarik Süresi
- 35 Weeks
- Material Flammability Rating
- UL94 V-0
- Actuatorcolor
- Black
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Resistance
- 100MOhm
- Contact Materials
- Phosphor Bronze
- Flat Flex Type
- FPC
