Volume pricing
- 1+ pcs$1.69
- 10+ pcs$1.59
- 100+ pcs$1.50
- 500+ pcs$1.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 500mA
- Özellikler
- Zero Insertion Force (ZIF)
- Gender
- Receptacle
- Locking Feature
- Slide Lock
- Uzunluk
- 26.5mm
- Montaj Tipi
- Surface Mount, Right Angle
- Genişlik
- 2.1mm
- Actuator Material
- Liquid Crystal Polymer (LCP)
- Nominal Gerilim
- 50V
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Finish Thickness
- 100.0μin 2.54μm
- Housing Material
- Liquid Crystal Polymer (LCP)
- Cable End Type
- Tapered
- Pozisyon Sayısı
- 40
- Housing Color
- Ivory
- Parça Durumu
- Discontinued
- Operating Supply Voltage
- 50V
- Sıra Sayısı
- 1
- Number Of Contacts
- 40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuatorcolor
- Black
- Material Flammability Rating
- UL94 V-0
- Pin Sayısı
- 40
- Terminal
- Solder
- Current Rating Amps
- 0.5A
- Maks. Çalışma Sıcaklığı
- 85°C
- Flammability Rating
- UL94 V-0
- Orientation
- Horizontal
- Lead Pitch
- 500μm
- Contact Location
- Top
- Ffc Fcb Thickness
- 0.30mm
- Ambalaj
- Cut Tape (CT)
- Contact Finish
- Tin
- Height Above Board
- 0.079 2.00mm
- Mating Cycles
- 25
- Montaj
- Surface Mount
- Contact Resistance
- 20mOhm
- Reach Svhc
- Unknown
- Pitch
- 0.020 0.50mm
- Min. Çalışma Sıcaklığı
- -25°C
