Specifications
- Contact Finish Post
- Tin
- Contact Shape
- Square
- RoHS Durumu
- ROHS3 Compliant
- Contact Type
- Male Pin
- Nominal Gerilim
- 250V
- Style
- Board to Cable/Wire
- Lead Pitch
- 3mm
- Contact Plating
- Tin
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pitch Mating
- 0.118 3.00mm
- Montaj Tipi
- Through Hole
- Contact Finish Mating
- Tin
- Pin Sayısı
- 2
- Contact Resistance
- 10mOhm
- Sıra Sayısı
- 1
- Seri
- WR-MPC3
- Current Rating Amps
- 5A
- Pitch
- 2.9972mm
- Contact Length Post
- 0.125 3.18mm
- Akım Değeri
- 5A
- Material Flammability Rating
- UL94 V-0
- Renk
- Black
- Insulation Color
- Black
- Connector Type
- Header
- Özellikler
- Board Guide
- Fabrika Tedarik Süresi
- 15 Weeks
- Maks. Çalışma Sıcaklığı
- 105°C
- Pozisyon Sayısı
- 2
- Parça Durumu
- Active
- Number Of Contacts
- 2
- Terminal
- Kinked Pin, Solder
- Operating Supply Voltage
- 250V
- Number Of Positions Loaded
- All
- Min. Çalışma Sıcaklığı
- -40°C
- Montaj
- Through Hole
- Fastening Type
- Locking Ramp
- Uzunluk
- 4.37mm
- Genişlik
- 9.65mm
- Shrouding
- Shrouded - 4 Wall
- Insulation Height
- 0.390 9.91mm
