Volume pricing
- 1+ pcs$0.62
- 10+ pcs$0.59
- 100+ pcs$0.55
- 500+ pcs$0.52
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Finish Mating
- Tin
- Maks. Çalışma Sıcaklığı
- 105°C
- Contact Gender
- Male
- Pitch Mating
- 0.165 4.20mm
- RoHS Durumu
- ROHS3 Compliant
- Contact Resistance
- 10mOhm
- Çalışma Sıcaklığı
- -40°C~105°C
- Insulation Resistance
- 1GOhm
- Number Of Positions Loaded
- All
- Insulation Color
- White
- Contact Finish Post
- Tin
- Contact Shape
- Square
- Özellikler
- Board Lock
- Contact Type
- Male Pin
- Seri
- WR-MPC4
- Montaj Tipi
- Through Hole, Right Angle
- Genişlik
- 22.3mm
- Number Of Contacts
- 10
- Insulation
- Insulated
- Renk
- White
- Current Rating Amps
- 7A
- Contact Length Post
- 0.138 3.50mm
- Ambalaj
- Tray
- Min. Çalışma Sıcaklığı
- -40°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Nylon
- Insulation Materials
- Polyamide (PA66), Nylon 6/6
- Lead Pitch
- 4.2mm
- Row Spacing Mating
- 0.165 (4.20mm)
- Akım Değeri
- 7A
- Contact Materials
- Nickel
- Flammability Rating
- UL94 V-0
- Yükseklik
- 12.8mm
- Style
- Board to Cable/Wire
- Sıra Sayısı
- 2
- Fastening Type
- Locking Ramp
- Shrouding
- Shrouded - 4 Wall
- Terminal
- Solder
- Uzunluk
- 22.2mm
- Pin Sayısı
- 10
