Volume pricing
- 1+ pcs$3.13
- 10+ pcs$2.95
- 100+ pcs$2.78
- 500+ pcs$2.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Male
- Reach Svhc
- Unknown
- Contact Plating
- Tin
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Parça Durumu
- Active
- Pozisyon Sayısı
- 18
- Insulation Height
- 0.364 9.25mm
- Pitch Mating
- 0.079 2.00mm
- Operating Supply Voltage
- 250V
- Özellikler
- Board Guide
- Current Rating Amps
- 3A
- Fastening Type
- Latch Holder
- Stack Height Mating
- 11.6mm
- Style
- Board to Cable/Wire
- Housing Material
- Polyester
- Insulation Color
- White
- Renk
- White
- Sıra Sayısı
- 2
- Contact Finish Mating
- Tin
- Connector Type
- Header
- Number Of Contacts
- 18
- Uzunluk
- 11.5mm
- Akım Değeri
- 3A
- Yükseklik
- 9.75mm
- Pitch
- 2.0066mm
- Lead Pitch
- 2mm
- Contact Shape
- Square
- Genişlik
- 21.4mm
- Row Spacing Mating
- 0.197 (5.00mm)
- Contact Materials
- Copper Alloy
- Contact Length Post
- 0.126 3.20mm
- Contact Resistance
- 20mOhm
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Fabrika Tedarik Süresi
- 11 Weeks
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Finish Post
- Tin
- Terminal
- Press-Fit, Solder
