Specifications
- Insulation Color
- Black
- Reach Svhc
- Unknown
- Material Flammability Rating
- UL94 V-0
- Pitch
- 1.27mm
- Style
- Board to Board or Cable
- Contact Length Post
- 0.091 2.30mm
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.059 1.50mm
- Pitch Mating
- 0.050 1.27mm
- Contact Shape
- Square
- Akım Değeri
- 1A
- Parça Durumu
- Active
- Insulation Materials
- Polyamide (PA6T), Nylon 6T
- Pin Sayısı
- 8
- Contact Plating
- Gold
- Nominal Gerilim
- 50V
- Contact Type
- Male Pin
- Operating Supply Voltage
- 100V
- Gender
- Male
- Contact Materials
- Copper Alloy
- Row Spacing Mating
- 0.050 (1.27mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Overall Contact Length
- 0.299 7.60mm
- Montaj
- Through Hole
- Ambalaj
- Bulk
- Pozisyon Sayısı
- 8
- Lead Pitch
- 1.27mm
- Current Rating Amps
- 1A
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 14 Weeks
- Sıra Sayısı
- 2
- Number Of Contacts
- 8
- Fastening Type
- Push-Pull
- Terminal
- Solder
- Shrouding
- Unshrouded
- Contact Finish Mating
- Gold
- Renk
- Black
- Çalışma Sıcaklığı
- -40°C~125°C
- Contact Resistance
- 20mOhm
