Specifications
- Contact Resistance
- 20mOhm
- Contact Finish Mating
- Gold
- Insulation Color
- Black
- Shrouding
- Unshrouded
- Contact Plating
- Gold
- Pin Sayısı
- 1
- Montaj
- Through Hole
- Fastening Type
- Push-Pull
- Contact Materials
- Copper Alloy
- Current Rating Amps
- 3A
- Nominal Gerilim
- 250V
- Pozisyon Sayısı
- 1
- Terminal
- Solder
- Renk
- Black
- Contact Length Post
- 0.118 3.00mm
- Akım Değeri
- 3A
- Number Of Positions Loaded
- All
- Orientation
- Vertical
- Number Of Contacts
- 1
- Style
- Board to Board or Cable
- Çalışma Sıcaklığı
- -40°C~105°C
- Montaj Tipi
- Through Hole
- Contact Lengthmating
- 0.236 6.00mm
- Insulation Height
- 0.100 2.54mm
- Material Flammability Rating
- UL94 V-0
- Gender
- Male
- Contact Type
- Male Pin
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 14 Weeks
- Parça Durumu
- Active
- Operating Supply Voltage
- 250V
- Contact Shape
- Square
- Overall Contact Length
- 0.454 11.54mm
- Seri
- WR-PHD
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Lead Pitch
- 2.54mm
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- Polybutylene Terephthalate (PBT)
