Volume pricing
- 1+ pcs$1.01
- 10+ pcs$0.95
- 100+ pcs$0.90
- 500+ pcs$0.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Color
- Black
- Montaj
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Contacts
- 26
- Yükseklik
- 8.85mm
- Material Flammability Rating
- UL94 V-0
- Style
- Board to Cable/Wire
- Number Of Positions Loaded
- All
- Özellikler
- Keying Slot
- Pitch
- 2.54mm
- Orientation
- Vertical
- Flammability Rating
- UL94 V-0
- Contact Materials
- Copper Alloy
- Ambalaj
- Tray
- Seri
- WR-BHD
- Montaj Tipi
- Through Hole
- Akım Değeri
- 3A
- Voltage Rated Dc
- 250V
- Contact Finish Mating
- Gold
- Genişlik
- 40.68mm
- Row Spacing Mating
- 0.100 (2.54mm)
- Renk
- Black
- Min. Çalışma Sıcaklığı
- -40°C
- Operating Supply Voltage
- 250V
- Fastening Type
- Push-Pull
- Contact Length Post
- 0.118 3.00mm
- Pitch Mating
- 0.100 2.54mm
- Contact Resistance
- 20mOhm
- Current Rating Amps
- 3A
- Contact Type
- Male Pin
- Contact Plating
- Gold
- Reach Svhc
- No SVHC
- Housing Material
- PBT
- Insulation Resistance
- 1GOhm
- Çalışma Sıcaklığı
- -40°C~125°C
- Contact Shape
- Square
- Insulation Height
- 0.358 9.10mm
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 15 Weeks
- Uzunluk
- 9.1mm
