Volume pricing
- 1+ pcs$1.58
- 10+ pcs$1.49
- 100+ pcs$1.40
- 500+ pcs$1.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 15 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.669 17.00mm
- Contact Shape
- Square
- Insulation Resistance
- 1GOhm
- Housing Material
- PBT
- Reach Svhc
- Unknown
- Çalışma Sıcaklığı
- -40°C~125°C
- Current Rating Amps
- 3A
- Contact Plating
- Gold
- Contact Type
- Male Pin
- Contact Resistance
- 20mOhm
- Fastening Type
- Latch Lock/Eject Hooks, Long
- Pitch Mating
- 0.100 2.54mm
- Contact Length Post
- 0.134 3.40mm
- Operating Supply Voltage
- 250V
- Min. Çalışma Sıcaklığı
- -40°C
- Renk
- Black
- Pin Sayısı
- 16
- Sıra Sayısı
- 2
- Terminal
- Solder
- Parça Durumu
- Active
- Lead Pitch
- 2.54mm
- Connector Type
- Header
- Shrouding
- Shrouded - 4 Wall
- Maks. Çalışma Sıcaklığı
- 125°C
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Contact Gender
- Male
- Nominal Gerilim
- 250V
- Pozisyon Sayısı
- 16
- Gender
- Male
- Uzunluk
- 17.78mm
- Orientation
- Vertical
- Pitch
- 2.54mm
- Number Of Positions Loaded
- All
- Style
- Board to Cable/Wire
- Özellikler
- Keying Slot
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 8.3mm
- Number Of Contacts
- 16
