Volume pricing
- 1+ pcs$8.06
- 10+ pcs$7.60
- 100+ pcs$7.17
- 500+ pcs$6.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Height
- 0.632 16.05mm
- Wire Cross Section
- 4 mm2
- Gerilim
- 300V
- Material Flammability Rating
- UL94 V-0
- Onay Kuruluşu
- CSA, UR
- Number Of Levels
- 1
- Akım
- 10A
- Seri
- Omnimate BL
- Currentul
- 20A
- Currentiec
- 23A
- Number Of Ways
- 9
- Wire Gauge Or Range Awg
- 12-30 AWG
- Wirecable Gauge
- 12 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Mating Finish
- Tin
- Stripping Length
- 7mm
- Reach Svhc
- Unknown
- Pitch
- 0.197 5.00mm
- Screw Size
- M2.5
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Wire Gauge Min
- 12 AWG
- Voltageiec
- 400V
- Safety Approval
- UL; CSA
- Renk
- Black
- Yayın Yılı
- 2010
- Connector Type
- Terminal Block
- Tip
- Plug, Female Sockets
- Montaj
- Free Hanging
- Housing Material
- Polybutylene Terephthalate (PBT)
- Number Of Poles
- 9
- Fabrika Tedarik Süresi
- 16 Weeks
- Parça Durumu
- Active
- Nominal Gerilim
- 300V
- Ambalaj
- Bulk
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Akım Değeri
- 15.5A
- Özellikler
- Retention Latches (Non-Wire Side)
- Wire Gauge Max
- 26 AWG
- Plug Wire Entry
- 180°
