Volume pricing
- 1+ pcs$9.46
- 10+ pcs$8.93
- 100+ pcs$8.42
- 500+ pcs$7.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Free Hanging (In-Line)
- Sıra Sayısı
- 1
- Wire Gauge Or Range Awg
- 12-30 AWG
- Wire Cross Section
- 4 mm2
- Plug Wire Entry
- 270°
- Number Of Decks
- 1
- Ambalaj
- Box
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Tip
- Plug, Female Sockets
- Wire Gauge Min
- 12 AWG
- Akım Değeri
- 13A
- Yayın Yılı
- 2010
- Reach Svhc
- Unknown
- Onay Kuruluşu
- CSA, UR
- Screw Size
- M2.5
- Flammability Rating
- UL94 V-0
- Number Of Poles
- 12
- Currentul
- 20A
- Currentiec
- 23A
- Number Of Levels
- 1
- HTS Kodu
- 8536.69.40.40
- Contact Mating Finish
- Tin
- Insulation Height
- 0.555 14.10mm
- Contact Materials
- Copper Alloy
- Additional Feature
- STANDARD: UL 94V-0
- Nominal Gerilim
- 300V
- Material Flammability Rating
- UL94 V-0
- Pitch
- 0.200 5.08mm
- Akım
- 10A
- Parça Durumu
- Active
- Voltageiec
- 400V
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 7mm
- Renk
- Black
- Terminal
- Screw
- Housing Material
- Polybutylene Terephthalate (PBT)
- Wirecable Gauge
- 12 AWG
- Seri
- Omnimate BL
- Connector Type
- Terminal Block
- Fabrika Tedarik Süresi
- 12 Weeks
