Volume pricing
- 1+ pcs$18.72
- 10+ pcs$17.66
- 100+ pcs$16.66
- 500+ pcs$15.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Wire Gauge Min
- 12 AWG
- Tip
- Plug, Female Sockets
- Akım Değeri
- 15A
- Yayın Yılı
- 2010
- Seri
- Omnimate BL
- Wire Cross Section
- 4 mm2
- Plug Wire Entry
- 90°
- Terminal
- Screw
- Number Of Decks
- 1
- Housing Material
- Polybutylene Terephthalate (PBT)
- Ambalaj
- Bulk
- Akım
- 10A
- Parça Durumu
- Active
- Voltageiec
- 400V
- Sıra Sayısı
- 1
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 7mm
- Wire Gauge Or Range Awg
- 12-30 AWG
- Renk
- Orange
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Pitch
- 0.200 5.08mm
- Safety Approval
- UL; CSA
- Contact Materials
- Copper Alloy
- Nominal Gerilim
- 300V
- Additional Feature
- STANDARD: UL 94V-0
- Number Of Ways
- 20
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Montaj
- Free Hanging
- ECCN Kodu
- EAR99
- Contact Mating Finish
- Tin
- Özellikler
- Retention Latches (Wire Side)
- Wire Gauge Max
- 26 AWG
- Insulation Height
- 0.555 14.10mm
- Çalışma Sıcaklığı
- -50°C~100°C
- Number Of Positions Per Level
- 20
- Currentul
- 20A
- Gerilim
- 300V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
