Volume pricing
- 1+ pcs$3.89
- 10+ pcs$3.67
- 100+ pcs$3.47
- 500+ pcs$3.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -50°C~100°C
- Wire Cross Section
- 4 mm2
- Montaj Tipi
- Free Hanging (In-Line)
- Pitch
- 0.200 5.08mm
- Screw Size
- M2.5
- Renk
- Orange
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Özellikler
- Retention Latches (Non-Wire Side)
- Reach Svhc
- No SVHC
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Onay Kuruluşu
- CSA, UR
- Orientation
- Right Angle
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Wire Gauge Or Range Awg
- 12-30 AWG
- Number Of Ways
- 3
- Safety Approval
- UL
- Akım Değeri
- 15.5A
- Nominal Gerilim
- 300V
- Stripping Length
- 7mm
- Seri
- Omnimate BL
- Wire Gauge Max
- 26 AWG
- Number Of Decks
- 1
- Gender
- Female
- ECCN Kodu
- EAR99
- Currentul
- 20A
- Terminal
- Screw
- Gerilim
- 300V
- Akım
- 10A
- Tip
- Plug, Female Sockets
- Radyasyon Dayanımı
- No
- Additional Feature
- PBT, STANDARD: UL 94V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Cable, Free Hanging
- Voltageiec
- 400V
- Housing Material
- Polybutylene Terephthalate (PBT)
- Contact Mating Finish
- Tin
- Currentiec
- 23A
