Specifications
- Currentul
- 10A
- Wire Gauge Or Range Awg
- 16-28 AWG
- Additional Feature
- STANDARD: UL 94V-0
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tip
- Plug, Female Sockets
- Sıra Sayısı
- 1
- Plug Wire Entry
- 180°
- Flammability Rating
- UL94 V-0
- Contact Mating Finish
- Tin
- Ambalaj
- Bulk
- Number Of Levels
- 1
- Pozisyon Sayısı
- 2
- Housing Material
- Polyamide (PA), Nylon, Glass Filled
- Nominal Gerilim
- 300V
- Number Of Ways
- 2
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Insulation Height
- 0.437 11.10mm
- Seri
- Omnimate BC
- Stripping Length
- 7mm
- Voltageiec
- 320V
- Insulation Materials
- Nylon
- Contact Materials
- Copper Alloy
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Renk
- Orange
- Safety Approval
- UL; CSA
- Ingress Protection
- IP20
- Akım Değeri
- 17.5A
- Fabrika Tedarik Süresi
- 12 Weeks
- HTS Kodu
- 8536.69.40.40
- Çalışma Sıcaklığı
- -50°C~120°C
- Onay Kuruluşu
- CSA, cURus
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Screw Size
- M2
- ECCN Kodu
- EAR99
- Pitch
- 0.150 3.81mm
- Özellikler
- Mating Flange
- Montaj Tipi
- Free Hanging (In-Line)
