Volume pricing
- 1+ pcs$5.86
- 10+ pcs$5.53
- 100+ pcs$5.22
- 500+ pcs$4.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Cross Section
- 2.5 mm2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Method
- SPRING LOADED
- Fabrika Tedarik Süresi
- 6 Weeks
- Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Parça Durumu
- Active
- Tip
- Ground, Earth
- Renk
- Green, Yellow
- Uzunluk
- 56.5mm
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 12-30 AWG
- Material Insulation
- Thermoplastic, Wemid
- Sıra Sayısı
- 3
- Yükseklik
- 38.5mm
- Seri
- Z
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Safety Approval
- UL; CSA; GL
- Wire Gauge Max
- 30 AWG
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Yayın Yılı
- 2012
- Housing Color
- Green
- Number Of Levels
- 1
- Rated Voltage
- 800V
- Terminal Stili
- Push In, Spring
- Number Of Ways
- 3
- Radyasyon Dayanımı
- No
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 12 AWG
- Orientation
- Straight
- Additional Feature
- STANDARD: 94V-0
- Stripping Length
- 10mm
- ECCN Kodu
- EAR99
- Genişlik
- 5.1mm
