Volume pricing
- 1+ pcs$5.17
- 10+ pcs$4.88
- 100+ pcs$4.60
- 500+ pcs$4.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 11 Weeks
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.69.40.40
- Renk
- Orange
- Pitch
- 0.138 3.50mm
- Screw Thread
- M2
- Akım Değeri
- 10A
- Kurşunsuz Kodu
- yes
- Number Of Positions Per Level
- 10
- Ambalaj
- Bulk
- Onay Kuruluşu
- CSA, UR
- Terminal
- Screw
- Montaj Tipi
- Through Hole
- Contact Plating
- Tin
- Hole Diameter
- 1.3 mm
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Montaj
- Through Hole
- Flammability Rating
- UL94 V-2
- Mating Orientation
- 45° (135°) Angle with Board
- Number Of Ways
- 10
- Radyasyon Dayanımı
- No
- Seri
- Omnimate LM
- Özellikler
- Interlocking (Side)
- Yayın Yılı
- 2015
- Parça Durumu
- Obsolete
- Nominal Gerilim
- 300V
- Number Of Decks
- 1
- Wire Gauge Min
- 14 AWG
- Wirecable Gauge
- 28 AWG
- Wire Gauge
- 14-28 AWG
- Wire Gauge Max
- 28 AWG
- Insulation Materials
- Nylon
- RoHS Durumu
- RoHS Compliant
- Contact Material Plating
- Copper Alloy - Tin Plated
- Safety Approval
- UL; VDE; CSA
- Number Of Levels
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Sıra Sayısı
- 1
- Çalışma Sıcaklığı
- -50°C~100°C
