Volume pricing
- 1+ pcs$5.73
- 10+ pcs$5.40
- 100+ pcs$5.10
- 500+ pcs$4.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Termination
- Screwless - Push Button Clamp
- Genişlik
- 14.3mm
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Parça Durumu
- Active
- Montaj
- Through Hole
- Mating Orientation
- Horizontal with Board
- Nominal Gerilim
- 300V
- Renk
- Black
- Wire Gauge Min
- 16 AWG
- Number Of Decks
- 1
- Montaj Tipi
- Through Hole
- Safety Approval
- UL; VDE; CSA
- Uzunluk
- 46.11mm
- Fastening Method
- PUSH-ON
- Terminal
- Solder
- Sıra Sayısı
- 1
- Orientation
- Right Angle
- Pitch
- 0.150 3.81mm
- Number Of Levels
- 1
- Radyasyon Dayanımı
- No
- Ambalaj
- Tube
- Contact Material Plating
- Copper Alloy - Tin Plated
- Additional Feature
- GLASS FILLED LCP, 94V-0
- Depth
- 14.3mm
- Contact Plating
- Tin
- Seri
- Omnimate LSF-SMT
- Yayın Yılı
- 2004
- Wire Gauge
- 16-24 AWG
- Max Current Rating
- 10A
- Akım
- 12A
- Flammability Rating
- UL94 V-0
- Hole Diameter
- 1.1 mm
- Wire Gauge Max
- 24 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 10A
- Max Supply Voltage
- 300V
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Stripping Length
- 8mm
- RoHS Durumu
- RoHS Compliant
