Volume pricing
- 1+ pcs$57.20
- 10+ pcs$53.96
- 100+ pcs$50.90
- 500+ pcs$48.02
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Insulation
- Thermoplastic, Wemid
- Orientation
- Straight
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Decks
- 1
- ECCN Kodu
- EAR99
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Number Of Levels
- 1
- Yükseklik
- 123.7mm
- Pozisyon Sayısı
- 2
- Parça Durumu
- Active
- Yayın Yılı
- 2012
- Wire Gauge Or Range Awg
- 500kcmil-00 AWG
- Stripping Length
- 40mm
- Voltageiec
- 1000V
- Gerilim
- 600V
- Genişlik
- 36mm
- Uzunluk
- 100mm
- Radyasyon Dayanımı
- No
- Akım
- 350A
- Safety Approval
- UL; CSA; CE
- Akım Değeri
- 415A
- Seri
- W
- Sıra Sayısı
- 2
- Currentul
- 380A
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 70-240mm2
- Renk
- Blue
- Fabrika Tedarik Süresi
- 8 Weeks
- Terminal Stili
- Screw
- Terminal Width
- 36.0mm
- Additional Feature
- STANDARD: UL 94V-0
- Nominal Gerilim
- 8kV
- RoHS Durumu
- RoHS Compliant
- Tip
- Feed Through
- Flammability Rating
- UL94 V-0
