Specifications
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 400V
- Fabrika Tedarik Süresi
- 8 Weeks
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Method
- SPRING LOADED
- Wire Gauge Min
- 14 AWG
- Akım Değeri
- 24A
- Wirecable Gauge
- 14 AWG
- Pozisyon Sayısı
- 2
- Number Of Levels
- 1
- Wire Gauge Max
- 26 AWG
- Material Insulation
- Thermoplastic, Wemid
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Additional Feature
- STANDARD: UL 94V-0
- Renk
- Green, Yellow
- Number Of Decks
- 1
- Uzunluk
- 62.5mm
- Stripping Length
- 10mm
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Flammability Rating
- UL94 V-0
- Seri
- Z
- Yükseklik
- 43.15mm
- ECCN Kodu
- EAR99
- Safety Approval
- CE
- Tip
- Ground, Earth
- Yayın Yılı
- 2012
- Wire Gauge Or Range Awg
- 14-26 AWG
- Onay Kuruluşu
- CE, IEC
- Nominal Gerilim
- 6kV
- Genişlik
- 5.1mm
- Terminal Stili
- Push In, Spring
