Volume pricing
- 1+ pcs$7.23
- 10+ pcs$6.82
- 100+ pcs$6.43
- 500+ pcs$6.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Renk
- Green
- Contact Materials
- Copper Alloy
- Number Of Levels
- 1
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- Not Applicable
- Mixed Contacts
- NO
- Mil Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 16-28 AWG
- Fabrika Tedarik Süresi
- 12 Weeks
- Terminal
- Screw
- Gerilim
- 300V
- Montaj
- Free Hanging, Panel
- Wire Strip Length
- 7mm
- Wire Gauge Min
- 16 AWG
- Özellikler
- Mating Flange
- Yayın Yılı
- 2003
- Currentiec
- 17.5A
- Montaj Tipi
- Free Hanging (In-Line)
- Option
- GENERAL PURPOSE
- Radyasyon Dayanımı
- No
- Voltageiec
- 320V
- Screw Size
- M2
- Housing Material
- Polyamide (PA), Nylon, Glass Filled
- Ambalaj
- Bulk
- Ingress Protection
- IP20
- Wire Gauge Max
- 28 AWG
- Contact Mating Finish
- Tin
- Seri
- Omnimate BC
- Insulation Resistance
- 5MOhm
- Din Conformance
- NO
- Akım
- 10A
- Insulation Height
- 0.411 10.44mm
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -50°C~120°C
- Pitch
- 0.150 3.81mm
- Genişlik
- 10.4mm
