Volume pricing
- 1+ pcs$4.58
- 10+ pcs$4.32
- 100+ pcs$4.08
- 500+ pcs$3.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Safety Approval
- UL; CSA; CE
- Wire Gauge Max
- 28 AWG
- Material Flammability Rating
- UL94 V-0
- Stripping Length
- 10mm
- Kurşunsuz Kodu
- yes
- Genişlik
- 3.5mm
- Terminal Stili
- Push In, Spring
- Number Of Decks
- 2
- Nominal Gerilim
- 6kV
- Fabrika Tedarik Süresi
- 12 Weeks
- Material Insulation
- Thermoplastic, Wemid
- Seri
- Z
- Gerilim
- 300V
- Wire Gauge Or Range Awg
- 16-28 AWG
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Number Of Ways
- 4
- Akım
- 10A
- Wire Gauge Or Range Mm
- 0.5-1.5mm2
- Uzunluk
- 75.5mm
- Voltageiec
- 500V
- ECCN Kodu
- EAR99
- Fastening Method
- SPRING LOADED
- Montaj
- Panel
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Wire Gauge Min
- 16 AWG
- Number Of Levels
- 2
- Akım Değeri
- 17.5A
- Renk
- Blue
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 49.5mm
- Currentiec
- 17.5A
- Yayın Yılı
- 2009
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 4
- Tip
- Feed Through
