Specifications
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Safety Approval
- UL; CSA; CE
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 28 AWG
- Terminal Stili
- Push In, Spring
- Genişlik
- 3.5mm
- Kurşunsuz Kodu
- yes
- Stripping Length
- 10mm
- Number Of Decks
- 2
- Pozisyon Sayısı
- 4
- Nominal Gerilim
- 6kV
- Fabrika Tedarik Süresi
- 6 Weeks
- Seri
- Z
- Gerilim
- 300V
- Material Insulation
- Thermoplastic, Wemid
- Wire Gauge Or Range Awg
- 16-28 AWG
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Number Of Ways
- 4
- Uzunluk
- 75.5mm
- Wire Gauge Or Range Mm
- 0.5-1.5mm2
- Akım
- 10A
- Voltageiec
- 500V
- ECCN Kodu
- EAR99
- Fastening Method
- SPRING LOADED
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Min
- 16 AWG
- Number Of Levels
- 2
- Akım Değeri
- 17.5A
- Renk
- Beige
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 49.5mm
- Yayın Yılı
- 2009
- Housing Material
- Nylon
- Currentiec
- 17.5A
- Sıra Sayısı
- 2
- Tip
- Feed Through
