Volume pricing
- 1+ pcs$4.84
- 10+ pcs$4.57
- 100+ pcs$4.31
- 500+ pcs$4.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Nylon
- Currentiec
- 24A
- Yayın Yılı
- 2009
- Radyasyon Dayanımı
- No
- Akım Değeri
- 24A
- Renk
- Beige
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 54.5mm
- Tip
- Feed Through
- Sıra Sayısı
- 4
- Parça Durumu
- Active
- Fastening Method
- SPRING LOADED
- Orientation
- Straight
- Wire Gauge Min
- 14 AWG
- Number Of Levels
- 2
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 14-30 AWG
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Material Insulation
- Thermoplastic, Wemid
- Seri
- Z
- Gerilim
- 600V
- Voltageiec
- 800V
- ECCN Kodu
- EAR99
- Akım
- 20A
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Uzunluk
- 72.5mm
- Wire Gauge Max
- 30 AWG
- Material Flammability Rating
- UL94 V-0
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Safety Approval
- UL; CSA; CE
- Nominal Gerilim
- 8kV
- Fabrika Tedarik Süresi
- 6 Weeks
- Genişlik
- 5.1mm
- Kurşunsuz Kodu
- yes
- Stripping Length
- 10mm
- Terminal Stili
- Push In, Spring
- Number Of Decks
- 2
