Volume pricing
- 1+ pcs$10.12
- 10+ pcs$9.55
- 100+ pcs$9.01
- 500+ pcs$8.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Circuits
- 2
- Kurşunsuz Kodu
- yes
- Renk
- Blue
- Safety Approval
- UL; CSA
- Wire Gauge Min
- 12 AWG
- ECCN Kodu
- EAR99
- Terminal Stili
- Push In, Spring
- Material Flammability Rating
- UL94 V-0
- Currentiec
- 20A
- Gerilim
- 300V
- Pozisyon Sayısı
- 6
- Number Of Levels
- 3
- Number Of Decks
- 3
- Parça Durumu
- Active
- Wire Gauge Max
- 26 AWG
- Voltageiec
- 500V
- Material Insulation
- Thermoplastic, Wemid
- Fastening Method
- SCREW
- Tip
- Feed Through
- Genişlik
- 5.1mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Nominal Gerilim
- 6kV
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 20A
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Yükseklik
- 69mm
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- Z
- Yayın Yılı
- 2012
- Wire Gauge Or Range Awg
- 12-26 AWG
- Flammability Rating
- UL94 V-0
- Akım
- 15A
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 4
- Stripping Length
- 10mm
- Uzunluk
- 110.5mm
