Volume pricing
- 1+ pcs$7.97
- 10+ pcs$7.52
- 100+ pcs$7.10
- 500+ pcs$6.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 12-26 AWG
- Genişlik
- 5.1mm
- Voltageiec
- 400V
- Seri
- Z
- ECCN Kodu
- EAR99
- Uzunluk
- 50.5mm
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 2
- Tip
- Disconnect
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Terminal Stili
- Push In, Spring
- Radyasyon Dayanımı
- No
- Stripping Length
- 10mm
- Akım
- 10A
- Material Insulation
- Thermoplastic, Wemid
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Safety Approval
- UL; CSA; CE
- Wire Gauge Min
- 12 AWG
- Disconnect Type
- Switch, Knife
- Gerilim
- 300V
- Additional Feature
- STANDARD: UL 94V-0
- Number Of Decks
- 1
- Yükseklik
- 43.5mm
- Number Of Ways
- 1
- Yayın Yılı
- 2012
- Nominal Gerilim
- 6kV
- Wire Gauge Max
- 26 AWG
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 10A
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 8 Weeks
- Fastening Method
- SPRING LOADED
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Renk
- Orange
