Volume pricing
- 1+ pcs$7.26
- 10+ pcs$6.85
- 100+ pcs$6.46
- 500+ pcs$6.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- UL; CSA; CE
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- Not Applicable
- HTS Kodu
- 8536.69.40.40
- Gerilim
- 300V
- Housing Material
- Nylon
- Wire Gauge Min
- 12 AWG
- Kurşunsuz
- Lead Free
- Yükseklik
- 43.5mm
- Number Of Decks
- 1
- Additional Feature
- STANDARD: UL 94V-0
- Yayın Yılı
- 2008
- Number Of Ways
- 1
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 10A
- Wire Gauge Max
- 26 AWG
- Nominal Gerilim
- 6kV
- Fastening Method
- SPRING LOADED
- Fabrika Tedarik Süresi
- 16 Weeks
- Min. Çalışma Sıcaklığı
- -50°C
- Number Of Levels
- 1
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Renk
- Beige
- Depth
- 5.1mm
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 400V
- Max Supply Voltage
- 300V
- Genişlik
- 5.1mm
- Wire Gauge Or Range Awg
- 12-26 AWG
- ECCN Kodu
- EAR99
- Seri
- Z
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Uzunluk
- 50.5mm
- Maks. Çalışma Sıcaklığı
- 120°C
- Sıra Sayısı
- 1
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Tip
- Disconnect
- Max Current Rating
- 10A
