Volume pricing
- 1+ pcs$5.93
- 10+ pcs$5.59
- 100+ pcs$5.28
- 500+ pcs$4.98
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 16 AWG
- Wire Gauge Or Range Mm
- 0.5-1.5mm2
- Kurşunsuz
- Lead Free
- Fastening Method
- SPRING LOADED
- Fabrika Tedarik Süresi
- 6 Weeks
- Safety Approval
- UL; CSA; CE
- Wire Gauge Max
- 30 AWG
- Nominal Gerilim
- 500V
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Wirecable Gauge
- 16 AWG
- Kurşunsuz Kodu
- yes
- Seri
- Z
- Housing Material
- Nylon
- Sıra Sayısı
- 1
- Tip
- Ground, Earth
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 10mm
- Number Of Decks
- 1
- Flammability Rating
- UL94 V-0
- Material Insulation
- Thermoplastic, Wemid
- Yayın Yılı
- 2002
- Number Of Levels
- 1
- Terminal
- Screw
- Yükseklik
- 36.5mm
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Renk
- Green, Yellow
- Wire Gauge Or Range Awg
- 16-30 AWG
- Uzunluk
- 54.5mm
- Number Of Ways
- 2
- Housing Color
- Green
- Akım Değeri
- 20A
- Radyasyon Dayanımı
- No
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 3.5mm
- Number Of Contacts
- 2
- Terminal Stili
- Push In, Spring
- Nem Hassasiyeti (MSL)
- Not Applicable
- Additional Feature
- STANDARD: UL 94V-0
- Material Flammability Rating
- UL94 V-0
