Specifications
- Uzunluk
- 61mm
- Akım
- 10A
- Material Flammability Rating
- UL94 V-0
- Total Number Of Contacts
- 10
- Terminal Stili
- Solder
- Din Conformance
- NO
- Additional Feature
- PANEL MOUNTABLE
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 15A
- Özellikler
- Mating Flange, Solder Retention
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Obsolete
- Montaj
- Through Hole
- Nominal Gerilim
- 300V
- Contact Tail Length
- 0.059 1.50mm
- Yükseklik
- 8.5mm
- Yayın Yılı
- 2008
- JESD-609 Kodu
- e3
- Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- Insulation Height
- 0.335 8.51mm
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- RoHS Durumu
- RoHS Compliant
- Iec Conformance
- NO
- Filter Feature
- NO
- Pitch
- 0.200 5.08mm
- Renk
- Black
- Currentiec
- 27.5A
- Mixed Contacts
- NO
- Montaj Tipi
- Through Hole
- Option
- GENERAL PURPOSE
- Number Of Poles
- 10
- Onay Kuruluşu
- CSA, UR
- Contact Mating Finish
- Tin
- Hole Diameter
- 1.5 mm
- Genişlik
- 12mm
- Header Orientation
- 90°, Right Angle
- Radyasyon Dayanımı
- No
- Gerilim
- 300V
- Kurşunsuz
- Lead Free
