Volume pricing
- 1+ pcs$2.73
- 10+ pcs$2.57
- 100+ pcs$2.43
- 500+ pcs$2.29
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Stripping Length
- 10mm
- Akım Değeri
- 24A
- RoHS Durumu
- RoHS Compliant
- Renk
- Blue
- Safety Approval
- UL; CSA; CE
- Fastening Method
- SPRING LOADED
- Genişlik
- 5.1mm
- Montaj
- Cable
- Number Of Ways
- 1
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Gerilim
- 600V
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 12 AWG
- Yayın Yılı
- 2012
- Number Of Levels
- 1
- Uzunluk
- 50.5mm
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 26 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Radyasyon Dayanımı
- No
- Terminal Stili
- Push In, Spring
- Seri
- Z
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Additional Feature
- STANDARD: UL 94V-0
- Fabrika Tedarik Süresi
- 6 Weeks
- Wire Gauge Or Range Awg
- 12-26 AWG
- Material Insulation
- Thermoplastic, Wemid
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 8kV
- Sıra Sayısı
- 3
- Tip
- Feed Through
- Pozisyon Sayısı
- 2
- Number Of Decks
- 1
- Akım
- 21A
- Yükseklik
- 43mm
- Voltageiec
- 800V
