Volume pricing
- 1+ pcs$12.72
- 10+ pcs$12.00
- 100+ pcs$11.32
- 500+ pcs$10.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 106mm
- Number Of Levels
- 1
- HTS Kodu
- 8536.69.40.40
- Orientation
- Straight
- Yayın Yılı
- 2012
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Gerilim
- 300V
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 8 AWG
- Fastening Method
- SPRING LOADED
- Genişlik
- 8mm
- Renk
- Beige
- Safety Approval
- UL; CSA; CE
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 41A
- Stripping Length
- 13mm
- Yükseklik
- 46.5mm
- Akım
- 33A
- Voltageiec
- 800V
- Number Of Decks
- 1
- Sıra Sayısı
- 1
- Tip
- Feed Through
- Wire Gauge Or Range Mm
- 0.5-10mm2
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 8kV
- Material Insulation
- Thermoplastic, Wemid
- Wire Gauge Or Range Awg
- 8-20 AWG
- ECCN Kodu
- EAR99
- Additional Feature
- STANDARD: UL 94V-0
- Fabrika Tedarik Süresi
- 8 Weeks
- Seri
- Z
- Terminal Width
- 8.0mm
- Parça Durumu
- Active
- Wire Gauge Max
- 20 AWG
- Number Of Contacts
- 2
- Terminal Stili
- Push In, Spring
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Radyasyon Dayanımı
- No
- Currentiec
- 41A
- Material Flammability Rating
- UL94 V-0
