Volume pricing
- 1+ pcs$2.67
- 10+ pcs$2.52
- 100+ pcs$2.38
- 500+ pcs$2.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 10 AWG
- ECCN Kodu
- EAR99
- Terminal Stili
- Push In, Spring
- Safety Approval
- UL; CSA; CE
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Nylon
- Kurşunsuz Kodu
- yes
- Renk
- Blue
- Number Of Levels
- 1
- Pozisyon Sayısı
- 3
- Terminal
- Screw
- Gerilim
- 600V
- Material Insulation
- Thermoplastic, Wemid
- Voltageiec
- 800V
- Parça Durumu
- Active
- Wire Gauge Max
- 26 AWG
- Number Of Decks
- 1
- Genişlik
- 6.1mm
- Number Of Contacts
- 3
- Tip
- Feed Through
- Fastening Method
- SPRING LOADED
- Additional Feature
- STANDARD: UL 94V-0
- Nominal Gerilim
- 8kV
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 32A
- Fabrika Tedarik Süresi
- 6 Weeks
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Nem Hassasiyeti (MSL)
- Not Applicable
- Seri
- Z
- Wire Gauge Or Range Mm
- 0.5-6mm2
- Yükseklik
- 45.5mm
- Akım
- 28A
- Number Of Ways
- 1
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 10-26 AWG
- Yayın Yılı
- 2009
- Uzunluk
- 61.5mm
- Stripping Length
- 10mm
- Wire Cross Section
- 4 mm2
- Radyasyon Dayanımı
- No
