Volume pricing
- 1+ pcs$7.02
- 10+ pcs$6.62
- 100+ pcs$6.25
- 500+ pcs$5.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Wire Gauge Max
- 26 AWG
- Number Of Decks
- 1
- Material Insulation
- Thermoplastic, Wemid
- Rated Current
- 65A
- Additional Feature
- STANDARD: UL 94V-0
- Fastening Method
- SPRING LOADED
- Rated Voltage
- 800V
- Genişlik
- 6.1mm
- Tip
- Ground, Earth
- Renk
- Green, Yellow
- Kurşunsuz Kodu
- yes
- Housing Material
- Nylon
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 10 AWG
- ECCN Kodu
- EAR99
- Terminal Stili
- Push In, Spring
- Safety Approval
- UL; CSA; CE
- Number Of Levels
- 1
- Wire Gauge Or Range Awg
- 10-26 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2009
- Number Of Ways
- 1
- Stripping Length
- 10mm
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Sıra Sayısı
- 2
- Uzunluk
- 61.5mm
- Housing Color
- Green
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Fabrika Tedarik Süresi
- 6 Weeks
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.5-6mm2
- Yükseklik
- 45.5mm
- Orientation
- Straight
- Seri
- Z
- Nem Hassasiyeti (MSL)
- Not Applicable
