Volume pricing
- 1+ pcs$2.54
- 10+ pcs$2.39
- 100+ pcs$2.26
- 500+ pcs$2.13
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Wire Gauge Max
- 26 AWG
- Number Of Decks
- 1
- Voltageiec
- 800V
- Material Insulation
- Thermoplastic, Wemid
- Additional Feature
- 94V-0
- Tip
- Feed Through
- Genişlik
- 6.1mm
- Number Of Contacts
- 2
- Renk
- Beige
- Kurşunsuz Kodu
- yes
- Housing Material
- Nylon
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL; CSA
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 10 AWG
- Terminal Stili
- Push In, Spring
- Number Of Levels
- 1
- Pozisyon Sayısı
- 2
- Terminal
- Screw
- Gerilim
- 600V
- Yayın Yılı
- 2009
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 10-26 AWG
- Number Of Ways
- 1
- Akım
- 28A
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Currentul
- 33A
- Sıra Sayısı
- 1
- Stripping Length
- 10mm
- Uzunluk
- 61.5mm
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Fabrika Tedarik Süresi
- 6 Weeks
- Akım Değeri
- 32A
- Nominal Gerilim
- 8kV
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.5-6mm2
- Yükseklik
- 45.5mm
