Specifications
- Wire Gauge Min
- 14 AWG
- Sıra Sayısı
- 3
- RoHS Durumu
- RoHS Compliant
- Onay Kuruluşu
- CSA
- Number Of Ways
- 4
- Montaj Tipi
- Through Hole
- Screw Thread
- M2.5
- Number Of Decks
- 3
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 300V
- Hole Diameter
- 1.3 mm
- Radyasyon Dayanımı
- No
- Contact Plating
- Tin
- Seri
- Omnimate LM
- Number Of Levels
- 3
- ECCN Kodu
- EAR99
- Positions Per Level
- 2
- Renk
- Orange
- Özellikler
- Interlocking (Side)
- Genişlik
- 31.8mm
- Yükseklik
- 36.6mm
- Kurşunsuz
- Lead Free
- Akım Değeri
- 10A
- Uzunluk
- 12.7mm
- Akım
- 15A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal And Terminal Block Type
- STRIP TERMINAL BLOCK
- Çalışma Sıcaklığı
- -50°C~120°C
- Parça Durumu
- Active
- Contact Material Plating
- Copper Alloy - Tin Plated
- Montaj
- Through Hole
- Yayın Yılı
- 2009
- Housing Material
- Thermoplastic, Wemid
- Fabrika Tedarik Süresi
- 12 Weeks
- Wire Gauge
- 14-24 AWG
- Mating Orientation
- Horizontal with Board
- Pozisyon Sayısı
- 6
- Orientation
- Straight
- Pitch
- 0.200 5.08mm
